Do You Know The Grating Strips In Uv Flatbed Printers?

When using a uv flatbed printer, we will see a fence on it. What is this for? Many friends are not very clear about the role of the power grid. Today, let the manufacturer introduce what the power grid of the uv flatbed printer is used for and what is special

The grille bar is a transparent grille bar that is installed behind the x-axis lateral movement guide rails of various types of equipment. According to the horizontal size of the equipment, there are specifications such as 0.6m, 1.6m, 2.5m, etc., which are also important factors that determine the printing range of the equipment. Generally speaking, the ruler of the uv tablet computer and the equipment of the uv printer will rotate the car left and right according to the actual size of the output pattern during the printing process. After the computer outputs the printing command, the printer head moves to the initial position. The grating bar sensor senses its scale and defines the correct printing interval.

The nozzle of the uv flatbed printer moves back and forth during the printing process, and outputs graphics according to the actual size of the pattern. This is what the grille does. A sensor is installed on the back of the uv flatbed mobile vehicle. After the computer outputs the printing command, when the mobile cart moves to the initial position, the fence acts as a ruler. The fence sensor behind the mobile cart senses the scale to define the correct printing interval.

The grille bar mainly plays a role of positioning. The interval between two vertical lines on the grille is the unit size. The grille decoder measures how many vertical lines the car has moved, and measures the size and position of the car's movement.
